K Series Helical-Bevel Gear Reducer

Right-angle helical-bevel reducer for compact 90-degree industrial drives, conveyors, packaging lines, and OEM machinery.

Key Range

Download documents

Technical Datasheets

Item	Data
Product name	K Series Helical-Bevel Gear Reducer
Product family	R/F/K/S modular gear reducer family
Transmission layout	Right-angle helical-bevel transmission
Model range	K37–K157 / SHK37–SHK157
Output speed	7–415 r/min
Power range	0.12–160 kW
Rated output torque	200–18,000 N·m
Output shaft diameter	Ø25–Ø120
Input forms	Direct motor, shaft input, flange input, motor adapter
Output forms	Solid shaft, hollow shaft, shrink disc, splined hollow shaft, output flange, torque arm
Best fit	Compact 90-degree drives, conveyor systems, packaging machinery, logistics equipment, and OEM machines

Current Series	Previous Type	Rated Output Torque	Output Shaft Diameter
SHK37	K37	200 N·m	Ø25
SHK47	K47	400 N·m	Ø30
SHK57	K57	600 N·m	Ø35
SHK67	K67	820 N·m	Ø40
SHK77	K77	1,550 N·m	Ø50
SHK87	K87	2,700 N·m	Ø60
SHK97	K97	4,300 N·m	Ø70
SHK107	K107	8,000 N·m	Ø90
SHK127	K127	13,000 N·m	Ø110
SHK157	K157	18,000 N·m	Ø120

Is KF a separate product from K Series?

KF is best treated as a flange-mounted or mounting-variant configuration under the K Series helical-bevel reducer direction. K is the main product series; KF is a configuration path that requires flange and mounting drawing confirmation.

What is the difference between K Series and R Series?

K Series uses a right-angle helical-bevel layout. R Series uses an inline helical layout. Use K when the motor and driven shaft need a 90-degree arrangement. Use R when the drive path remains straight.

What is the difference between K Series and F Series?

K Series is right-angle helical-bevel. F Series is parallel shaft helical. Use K when the machine needs 90-degree output. Use F when the motor and driven shaft need to stay parallel.

What is the difference between K Series and S Series?

K Series uses helical-bevel transmission and is better suited for higher-efficiency and stronger right-angle drive requirements. S Series uses helical-worm transmission and is more compact and economical for some lower-torque right-angle applications.

What is the difference between K Series and NMRV worm reducer?

K Series is a modular helical-bevel right-angle reducer with stronger torque and efficiency direction. NMRV / RV is a compact worm gear reducer for cost-sensitive small and medium right-angle drive positions.

Can K Series be supplied with a hollow shaft?

Yes. K Series can be reviewed with hollow shaft, shrink disc, splined hollow shaft, flange, and torque arm configurations according to the selected model and drawing.

Can K Series be supplied with a motor?

Yes. K Series can be supplied as a geared motor package. Motor options may include standard motor, brake motor, variable-frequency motor, multi-speed motor, and other confirmed configurations.

Can K Series be used with a frequency converter?

A variable-frequency motor or inverter-compatible motor package should be reviewed when speed control is required. SV200 frequency converter and YVF motor options can be checked as part of the drive package.

What information is needed before quotation?

Send motor power, input speed, required output speed, ratio, output torque, mounting form, shaft form, hollow shaft bore if required, torque arm requirement, duty cycle, and working environment. For replacement, include the old nameplate and installation drawing.

Can Starshine provide drawings and CAD files?

2D drawings and 3D CAD files can be requested after reducer size, ratio, mounting form, output shaft, motor option, flange requirement, and installation direction are confirmed.
